Antenna


Large Antenna

size Fréquence Fiche technique
4,50 m C, X, Ku, Ka large_antenna_4.5m.pdf pdf
6,20 m C, X, Ku, Ka large_antenna_6.2m.pdf pdf
7,30 m C, X, Ku, Ka large_antenna_7.3m.pdf pdf
9.0 m C, X, Ku, Ka large_antenna_9m.pdf pdf
11,30 m C, X, Ku, Ka large_antenna_11.30m.pdf pdf
13,20 m C, X, Ku, Ka large_antenna_13.20m.pdf pdf

Fly Away

size Fréquence Type motorized Fiche technique
0.9 m C, X, Ku, Ka dual reflector yes flyaway_antenna_0.9m_automatic.pdf pdf
1,20 m C, X, Ku, Ka dual reflector yes flyaway_antenna_1.2m_automatic.pdf pdf
1,20 m C, X, Ku, Ka Offset no flyaway_antenna_1.2m_manual.pdf pdf
1,80 m C, X, Ku, Ka Offset yes flyaway_antenna_1.8m_automatic.pdf pdf
1,80 m C, X, Ku, Ka Offset no flyaway_antenna_1.8m_manual.pdf pdf

COTM

size Fréquence Fiche technique
0,9 m X Band cotm_0.9.pdf pdf
0.9 m Ku Band cotm_0.9_ku.pdf pdf

CONTROLLER

Modèle Fiche technique
8200 antenna_control_system.pdf pdf
Système sur-mesure sales@eurosatcom.eu

Buc SSPA


C Band

Puissance* Package Technologie Consommation Fiche technique
20 - 40W Outdoor GaAs 140 - 220W buc_sspa_c_20_40w.pdf pdf
80 - 100W Outdoor GaN 80 - 100W buc_sspa_c_80_100w.pdf pdf
150 - 400W Outdoor GaN 650 - 1800W buc_sspa_c_150_400w.pdf pdf
600 - 800W Outdoor GaN 2300 - 2750W buc_sspa_c_600_800w.pdf pdf
50 - 400W Indoor GaN 260 - 2000W buc_sspa_c_ku_indoor_50_400w.pdf pdf

*GaAS: P1dB, GaN: Psat

Système sur-mesure sales@eurosatcom.eu

X Band

Puissance* Package Technologie Consommation Fiche technique
10 - 40W Outdoor GaAs 100 - 300W buc_sspa_x_10_40w_acmb_x_lp.pdf pdf
80 - 100W Outdoor GaAs 600 - 650W buc_sspa_x_80_100w_acmb_x_mp.pdf pdf
150 - 200W Outdoor GaAs 1200 - 1300W buc_sspa_x_150_200w_actx_x_hp.pdf pdf

*GaAS: P1dB, GaN: Psat

Ku Band

Puissance* Package Technologie Consommation Fiche technique
16 - 25W Outdoor GaAs 135 - 200W buc_sspa_ku_16_25w.pdf pdf
40 - 50W Outdoor GaN 250 - 280W buc_sspa_ku_40_50w.pdf pdf
60 - 100W Outdoor GaN 450 - 600W buc_sspa_ku_60_100w.pdf pdf
150 - 200W Outdoor GaN 1000 - 1150W buc_sspa_ku_150_200w.pdf pdf
250 - 400W Outdoor GaN 1500 - 2150W buc_sspa_ku_250_400w.pdf pdf
400 - 600W Outdoor GaN 3000 - 4000W buc_sspa_ku_400_600w.pdf pdf
50 - 400W Indoor GaN 260 - 2000W buc_sspa_c_ku_indoor_50_400w.pdf pdf

*GaAS: P1dB, GaN: Psat

Ka Band

Puissance* Fréquence Package Technologie Consommation Fiche technique
4 - 8W 27.5 - 31.0 GHz Outdoor GaN 35 - 45W buc_sspa_ka_4_8w_actx_4_8w_ex_v5.pdf pdf
20W 27.5 - 31.0 GHz Outdoor GaN 150W buc_sspa_ka_20w_actx_20w_ex_v4.pdf pdf
20W Dual Band 29.0 - 31.0 GHz Outdoor GaN 150W buc_sspa_dual_ka_20w_actx_20w_e31_v4.pdf pdf
40 - 80W 29,5 - 31.0 GHz Outdoor GaN 300 - 650W buc_sspa_ka_40_80w_actx_40_80.pdf pdf

*GaAS: P1dB, GaN: Psat

Redundancy System

Puissance Fréquence Fiche technique
20 - 400W C Band buc_sspa_redundancy_kit.pdf pdf
16 - 400W Ku Band buc_sspa_redundancy_kit.pdf pdf

LNA/LNB


LNB

Modèle frequency* Noise figure Fiche technique
ACLNBS-Ka Standard Series 19.2 - 22.2 GHz 1.5 dB lnb_ka_standard_series_aclnbs_ka_ex_v3.pdf pdf
ACLNBP-Ka Premium Series 20.2 - 21.2 GHz 1.3 dB lnb_ka_premium_series_aclnbp_ka_ex_v4.pdf pdf
ACLNBD-Ka Dual Band Series 19.2 - 21.2 GHz 1.6 dB lnb_ka_dual_band_aclnbd_ka_e11_v2.pdf pdf
ACLNBD-Ka Dual Band Series Simult. outputs 19.2 - 21.2 GHz 1.6 dB lnb_ka_dual_band_multi_2_output_aclnbd_ka_e11_v3.pdf pdf
ACLNBW-Ka Wideband Series 17.7 - 21.2 GHz 1.8 dB lnb_ka_wide_4_band_aclnbw_ka_e33_v2.pdf pdf
ACLNBW-Ka Wideband Series Simult. Outputs 17.7 - 21.2 GHz 1.8 dB lnb_ka_wide_multi_4_output_aclnbw_ka_e33_v3.pdf pdf
ACLNBW-Ka Ultra-Wideband Series 17.7 - 22.2 GHz 1.8 dB lnb_ka_ultra_wide_5_band_aclnbw_ka_e45_v2.pdf pdf
ACLNBW-Ka Ultra-Wideband Series Simult.Outputs 17.7 - 22.2 GHz 1.8 dB lnb_ka_ultra_wide_multi_4_output_aclnbw_ka_e45_v3.pdf pdf
Système sur-mesure sales@eurosatcom.eu

LNA

Modèle frequency* Noise figure Fiche technique
ACLNA-Ka Wideband 17.7 - 21.2 GHz 1.6 dB lna_ka_wide_band_aclna_ka_e33_v1.pdf pdf
ACLNA-Ka Ultra-Wideband 17.7 - 22.2 GHz 1.8 dB lna_ka_ultra_wide_band_aclna_ka_e45_v1.pdf pdf
Système sur-mesure sales@eurosatcom.eu

Switch


Non-blocking MATRIX

Fréquence configuration* Fiche technique
IF: 20 - 200 MHz 8 x 8 matrix_if_8x8_mas2055.pdf pdf
IF: 40 - 200 MHz 16 x 16 matrix_if_16x16_mas2814.pdf pdf
IF: 20 - 200 MHz 32 x 32 matrix_if_32x32_mas2053.pdf pdf
IF: 20 - 200 MHz 64 x 64 matrix_if_64x64_mas2050.pdf pdf
IF-L Band: 30 - 2150 MHz 4 x 4 matrix_l_if_4x4_mas4452.pdf pdf
L Band: 950 - 2150 MHz 8 x 8 matrix_l_band_8x8_mas4478.pdf pdf
L band: 950 - 2150 MHz 16 x 16 matrix_l_band_16x16_mas5160.pdf pdf
L Band: 950 - 2150 MHz 32 x 2 matrix_l_band_32x2_mas2291.pdf pdf
L Band: 950 - 2150 MHz 64 x 8 matrix_l_band_64x8_mas2541.pdf pdf
L Band: 950 - 2150 MHz 128 x 8 matrix_l_band_128x8_mas2544.pdf pdf
IF-C Band: 20 - 4200 MHz 8 x 8 matrix_broadband_8x8_mas4489.pdf pdf
C-Ka Band: 3400 - 26500 MHz 4 x 8 matrix_broadband_c_ka_4x8_mas4500.pdf pdf

Many other configurations available at different frequencies (sales@eurosatcom.eu)

Switching Unit

Fréquence Type configuration* Fiche technique
15 - 230MHz Redundancy 2+1 with line amplifiers switching_unit_if_2_1_gts5635.pdf pdf
5850 - 6425 MHz Redundancy 2+1 with line amplifiers switching_unit_c_2_1_gts6872.pdf pdf
0.15 - 230 MHz Redundancy 8+1 switching_unit_if_8_1_gts0100.pdf pdf
1 - 3000 MHz Monitoring & Control 16 x 1 switching_unit_if_l_1x16_gts7010.pdf pdf
950 -2150MHz Monitoring & Control 64 x 1 switching_unit_l_64x1_gts1700.pdf pdf

Many other configurations available at different frequencies (sales@eurosatcom.eu)

Waveguide

Type Fiche technique
Flexible - rigid wg_assy_rigid_comp.pdf pdf
WG-Coax Adapter wg_coax_adapters.pdf pdf
Termination wg_termination.pdf pdf
Coupler wg_couplers.pdf pdf
Quick release wg_quick_release_syst.pdf pdf
Conversion chart wg_conv_chart.pdf pdf
Flange gasket wg_gasket.pdf pdf
Système sur-mesure sales@eurosatcom.eu

DC-DC Converters


SPACE GRADE DC-DC CONVERTERS

Maximum Power Output 2.5 Watts 5 Watts 6.5 Watts 10 Watts 20 Watts 30 Watts 40 Watts 80 Watts 500 Watts
12 VDC Input for Cubesats/Miniaturized Sat * 3699
28 VDC Input Spacecraft Bus Low Power / High Efficiency * 4690
28 VDC Input Spacecraft Bus * 53080 5690 99200 5107 5680
53600
5193
53629
5031 53696
50 VDC Input Spacecraft Bus * 7690 7107 7680 7193 7031 73696
70 VDC Input Spacecraft Bus * 8690 8107 8680 8193 8031 83696
100 VDC Input Spacecraft Bus * 9690 9107 9680 9193 9031 93696
120 VDC Input Space Station 3325 3070 3108 3060 3326 3051 33696
  • Proton Rad Hard 100K+®
    Custom Request: sales@eurosatcom.eu

POINT OF LOAD REGULATORS

Maximum Power Output 2.5 Watts 5 Watts 6.5 Watts 10 Watts 20 Watts 30 Watts 40 Watts 80 Watts
5 VDC Input Non-Isolated Series * 5085 5087
12 VDC Input Non-Isolated Series * 5080 5082
16 VDC Input Non-Isolated Series For Cubesats/Miniaturized Satellites * 3693 3694
  • Proton Rad Hard 100K+®
    Custom Request: sales@eurosatcom.eu

HYBRID EMI FILTERS SELECTIONS

Input Voltage 12 VDC 28 VDC 50 VDC 70 VDC 100 VDC 120 VDC 270 VDC
Hybrid EMI Filter Meets MIL-STD-461D/E/F/G CE102 Requirements 13678 53678 73678 83678 93678 33678 23678
  • Proton Rad Hard 100K+®
    Custom Request: sales@eurosatcom.eu

STANDARD MIL-AERO DC-DC CONVERTER

Maximum Power Output 2.5 Watts 5 Watts 6.5 Watts 10 Watts 20 Watts 30 Watts 40 Watts 80 Watts 100 Watts
5 VDC Input Series Standard 3650
8 ~ 40 VDC Low Input Voltage Range 3061 3062 3113 3378 3114
9 ~ 50 VDC Input 3718
28 VDC Input Series Standard 3715 3080 3716 3011 3001
3138
3600
270 VDC Input Advanced Aircraft 3020 3109 3000 3327 3041

Custom Request: sales@eurosatcom.eu

461D/E/F/G DC-DC CONVERTER SELECTION

Maximum Power Output 2.5 Watts 5 Watts 6.5 Watts 10 Watts 20 Watts 30 Watts 40 Watts 80 Watts
28 VDC MIL-STD-461D/E/F/G 3090 6681
28 VDC MIL-STD-1275D 3656

Custom Request: sales@eurosatcom.eu

INDUSTRIAL/RAILWAY GRADE DC-DC CONVERTER SELECTION

Maximum Power Output 2.5 Watts 5 Watts 6.5 Watts 10 Watts 20 Watts 30 Watts 40 Watts 80 Watts
24 VDC Input Series 16080 1690 1607 1680 1693 1631
110 VDC Input Series 1790 1707 1780 1793 1731

Custom Request: sales@eurosatcom.eu

STANDARD INRUSH LIMITER SELECTION

Input Voltage 28 VDC 50 VDC 70 VDC 100 VDC 120 VDC
Proton Rad Hard 100K+® Programmable Inrush Limiter 53635 73635 83635 93635 33635
Proton Rad Hard 100K+® MagLatch Inrush Limiter 53646 73646 83646 93646 33646

Custom Request: sales@eurosatcom.eu

STANDARD SOLID STATE SWITCH FUNCTIONS SELECTION

Input Voltage 28 VDC 50 VDC 70 VDC 100 VDC 120 VDC
150 VDC Proton Rad Hard 100K+® Solid State Relay 53647 73647
250 VDC Proton Rad Hard 100K+® Solid State Relay 83647 93647 33647

Custom Request: sales@eurosatcom.eu

BUS MASTER HYBRID MODULE SELECTION

Input Voltage 28 VDC 50 VDC 70 VDC 100 VDC 120 VDC
Proton Rad Hard 100K+® Bus Master Hybrid Module 53649 73649 83649 93649 33649

Custom Request: sales@eurosatcom.eu

ACTIVE "OR" HYBRID MODULE SELECTION

Input Voltage 1 to 4 VDC 1 to 7 VDC -1 to -4 VDC -1 to -7 VDC
Proton Rad Hard 100K+® Active Diode OR Hybrid Module 53653-3.3 53653-5.0 53654-3.3 53654-5.0

Custom Request: sales@eurosatcom.eu

ANCILLARY PRODUCT LINE UP

Description Model
Booster Hybrid DC-DC converters 3439
Output Sequenced Power Converters 99200
Triple Output High Efficiency DC-DC Converters 3600
High Efficiency Cross Regulated Triple Output Converters 53600
High Efficiency Cross Regulated Quad Output Converters 53629

Custom Request: sales@eurosatcom.eu

Système sur-mesure sales@eurosatcom.eu
